How to Receive Webhooks on HTTP Endpoints

Setting up your webhook connection

The first step is to create a connection which indicates to Hookdeck where you are expecting your webhooks to be delivered. A connection consists of the following:

Receiving your webhook URL

After creating your connection, you will receive a webhook URL that is tied to your Source. You have to use this Hookdeck URL instead of your HTTP endpoint when you are setting your endpoint on your API provider.

Testing to validate it works

After setting Hookdeck's URL as your endpoint, when the API provider sends a webhook you should receive them at your destination as well as see them in Hookdeck's dashboard. You can validate the behavior by:

• Sending a test webhook to the Hookdeck's URL
• Triggering an event from the API provider

Create a webhook connection

When creating a connection using the API, you will need to input the following parameters:

Connection: Relationship between the webhook sender and webhook consumer

• alias : human readable name for the connection

Source : webhook sender

• alias: human readable name for the source
• label: label for your source

Destination: webhook consumer

• alias: human readable name for the destination
• label: label for your destination
• url: where you want to receive your webhook, either an HTTP endpoint or your localhost to receive webhooks to your local server using Hookdeck's CLI.

{
  "alias": "mysource-to-myapi",
  "source": {
    "alias":"mysource",
    "label": "mysource"
  },
  "destination": {
    "alias": "myapi",
    "label": "myapi",
    "url": "https://example.com/webhook"
  }
}

We will not expand on rulesets in this guide since this does not impact our ability to receive a webhook. Something to note is that when we create a connection using Hookdeck's API, the ruleset will automatically be set to default ruleset unless specified.

Receiving your webhook URL

After creating your connection, the response will include many parameters related to the webhook connection. The parameters we are interested in are:

1. id: you will need the id to query events related to your webhook connection.
2. url: parameter within the Source object. You have to use this URL instead of your HTTP endpoint when you are setting your webhook on your API provider.

Example of response (trimmed down to show the relevant information):

{
"id": "web_mAJbMKUCt4QDxtfTahqbub7X",
"source": {
    "url": "https://events.hookdeck.com/e/src_cnsv4W1wixpFDvACwAAlkLCi
		},
}

Testing to validate if it works

After setting Hookdeck's URL as your endpoint, you should be receiving the webhooks the API provider sends to your destination. You can test you are receiving webhooks by:

• Sending a test webhook to Hookdeck's URL
• Triggering an event from the API provider

To validate if it works, you can query the API to see the events associated with the connection.

https://api.hookdeck.com/events?webhook_id=web_mAJbMKUCt4QDxtfTahqbub7X

Setting up GitHub webhook connection

In this example, we are going to subscribe to GitHub's Branch or tag creation event and then trigger a webhook to inspect the request data. Our goal is to understand the payload to eventually create an integration by writing code to respond to it.

Create a webhook connection for GitHub

Let's create a connection in Hookdeck to receive a webhook URL that we will use for GitHub's webhook registration.

1. Select Create in the Connections view.
2. Select "New" under Source. Set the Source Label as Github.
3. Select "New" under Destination: Set the Destination Label as Mock API, and the Destination URL as https://mock.hookdeck.com.
4. Select the Default Ruleset.
5. Click Create.

After creating the connection, our connection will look something like this. Take note of the Webhook URL for the next step.

Set Hookdeck URL in GitHub

We are going to add a webhook to our GitHub repository.

1. Go in Settings of your repository.

2. Select the "Webhooks" tab.

1. Click Add webhook.

1. Paste Hookdeck's webhook URL in Payload URL.
2. Select the content type application/json.
3. Choose "Let me select individual events" and select the Branch or tag creation event.

1. Click Add webhook.

Great! We added a webhook that will send us an event every time a branch or tag is created.

Create a branch to trigger a webhook

We are now going to create a branch called New Branch from master to trigger a webhook.

Validate and inspect webhook in Hookdeck

After creating a branch, the webhook becomes visible in the dashboard. When we click on the webhook, we can inspect the request's body.

Setting up a GitHub webhook connection

In our example, we are going to subscribe to GitHub's Branch or tag creation event and then trigger a webhook to inspect the request data. Our goal is to understand the payload to eventually create an integration by writing code to respond to it.

In this tutorial I will be using Postman for my API calls.

Create a webhook connection for GitHub

Let's create a connection with Hookdeck's API to receive a webhook URL that we will use for GitHub's webhook registration.

Authentication

We need to set up the authentication to have access to Hookdeck's API.

1. Retrieve your key under Workspace Settings.

1. Open Postman and choose the Authorization tab.
2. Select the type Basic Auth.
3. Enter the API as the username.

To send a request to create the webhook connection:

1. Select POST.

2. Enter the following URL https://api.hookdeck.com/connections.

3. Select Body > raw > JSON.

4. Enter the following payload:

   JSON

   {
     "alias": "github-to-mockapi",
     "source": {
       "alias":"github",
       "label": "github"
     },
     "destination": {
       "alias": "mockapi",
       "label": "mockapi",
       "url": "https://mock.hookdeck.com"
     }
   }


5. Click send.

You should receive a response with the following parameters:

{
    "id": "web_bKvPP9qnF16kNdR1XBMtK6aJ",
    "label": "mockapi",
    "alias": "github-to-mockapi",
    "team_id": "tm_6PPg9VoEqV51I4ks9f4hzRdT",
    "archived_at": null,
    "updated_at": "2021-06-17T20:19:06.550Z",
    "created_at": "2021-06-17T20:19:06.582Z",
    "filters": null,
    "destination": {
        "id": "des_0x7haWX4S9kQ5tAf3sHiprwA",
        "team_id": "tm_6PPg9VoEqV51I4ks9f4hzRdT",
        "label": "mockapi",
        "alias": "mockapi",
        "url": "https://mock.hookdeck.com",
        "archived_at": null,
        "updated_at": "2021-06-17T20:19:06.566Z",
        "created_at": "2021-06-17T20:19:06.563Z",
        "rate_limit": null,
        "rate_limit_period": "second",
        "cli_path": null,
        "path_forwarding_disabled": false
    },
    "source": {
        "id": "src_G0NVftI704HYkseIslCctiyE",
        "team_id": "tm_6PPg9VoEqV51I4ks9f4hzRdT",
        "label": "github",
        "alias": "github",
        "archived_at": null,
        "updated_at": "2021-06-17T20:19:06.560Z",
        "created_at": "2021-06-17T02:01:54.950Z",
        "integration_id": null,
        "url": "https://events.hookdeck.com/e/src_G0NVftI704HYkseIslCctiyE"
    },
    "ruleset": {
        "id": "rls_ITsLdTz80SoBUWW9a3GM6sw5",
        "alias": "default-ruleset",
        "team_id": "tm_6PPg9VoEqV51I4ks9f4hzRdT",
        "label": "Default Ruleset",
        "retry_count": 5,
        "retry_interval": 3600000,
        "retry_strategy": "linear",
        "is_team_default": true,
        "archived_at": null,
        "updated_at": "2021-05-07T21:19:35.607Z",
        "created_at": "2021-05-07T21:19:35.606Z",
        "alert_interval": 86400000,
        "alert_strategy": "last_attempt"
    }
}

We are going to omit the ruleset object for now; we are interested in the id and the url under source for the following steps.

Set Hookdeck URL in GitHub

We are going to add a webhook to our GitHub repository.

1. Go in Settings of your repository.

1. Select the "Webhooks" tab.

1. Click Add webhook.

1. Paste the url in Payload URL.

2. Select the content type application/json.

3. Choose "Let me select individual events" and select the Branch or tag creation event.

4. Click Add webhook.

Great, we added a webhook that will send us an event every time a branch or tag is created.

Create a branch to trigger a webhook

We are now going to create a branch called API-Branch from "master" to trigger a webhook.

Validate and inspect webhook in Hookdeck

After creating a branch, we want to query the API to validate if GitHub sent a webhook to our connection.

GET https://api.hookdeck.com/events?webhook_id=web_bKvPP9qnF16kNdR1XBMtK6aJ

Response:

{
    "pagination": {
        "order_by": "created_at",
        "dir": "desc",
        "limit": 100
    },
    "count": 1,
    "models": [
        {
            "id": "evt_8d1ZvFEq6bSpp24j4mCvgI5j",
            "team_id": "tm_6PPg9VoEqV51I4ks9f4hzRdT",
            "webhook_id": "web_bKvPP9qnF16kNdR1XBMtK6aJ",
            "source_id": "src_G0NVftI704HYkseIslCctiyE",
            "destination_id": "des_0x7haWX4S9kQ5tAf3sHiprwA",
            "attempts": 1,
            "response_status": 200,
            "last_attempt_at": "2021-06-17T20:25:27.678Z",
            "next_attempt_at": null,
            "successful_at": "2021-06-17T20:25:27.822Z",
            "updated_at": "2021-06-17T20:25:27.839Z",
            "created_at": "2021-06-17T20:25:27.501Z",
            "status": "NONE",
            "event_request_id": "evtreq_ajmfCUF4h9kFV4EHeKoutTiZ",
            "cli_id": null
        }
    ]
}

We can see that we received an event associated with the connnection. Let's dig in deeper to inspect the event by using ther event's id. id: "evt_8d1ZvFEq6bSpp24j4mCvgI5j"

GET https://api.hookdeck.com/events/evt_8d1ZvFEq6bSpp24j4mCvgI5j

Response (trimmed down to show the relevant information):

{
    "id": "evt_8d1ZvFEq6bSpp24j4mCvgI5j",
    "request": {
        "body": {
            "ref": "refs/heads/API-Branch"
								}
							}
}

Something to note is we can also use the event id to inspect the webhook in the Hookdeck dashboard. We highly recommend it, as visualizing the webhook payload can be helpful for the testing and development workflow.

https://dashboard.hookdeck.com/events?selected_event_id=evt_8d1ZvFEq6bSpp24j4mCvgI5j

Great, we can see in our API request and in Hookdeck's dashboard that the webhook event was indeed for creating our new branch called API-Branch.
